Facade system MTH-v-100
Concealed fixing of cassette panels

The system is available in two configurations.
— The first option is a system standardized to fit into other system types: well-known T-section that can be combined with other systems. Adjustment range of vertical rustic joint is wide due to wide carriages (80mm).

— The second option: A harder K-section is used. Cassettes may be mounted with the use of latches as well as
by means of cuts at cassette edges.
General information for both options: Fasteners for assembling cassettes are included in the system delivery
set. Position of carriages can be adjusted after cassettes are installed and are fixed by a preset screw.
Installation of wider cassettes is possible with the use of clips.

— Facing material: cassettes made of sheet composite materials.
Mounting configuration of facing material: by means of latches.
Max facing sizes: 1500х3000mm (horizontally and vertically).
Offset of facing from the wall surface: 97 to 600mm.

Mounting configuration of brackets:
— standard: mounting to the walls
— interfloor: mounting in the floor slabs.

Max allowed height: no height restrictions.
