The facade system MTC-v-350
Fixing terracotta tiles

— A large range of aluminum and stainless steel capping strips and allow to mount virtually any boards on the market.
— Perhaps both horizontal and vertical mounting plates.
— Clips from EPDM (TPE), which are equipped with aluminum clamps and straps, prevent vibration and horizontal offset plates.
— Mounting on rails allows not to tie vertical rusty cladding to the vertical profiles of the system and strengthen the lining "in the Extension."
— Possible rapid installation and removal of plates.
— Lining material: solid and hollow ceramic plate.
— Method of attachment facing material: clamps, straps concealed mounting.
— Maximum size of the lining: 1800h600mm (horizontal and vertical position).
— Removal of the cladding material from the plane of the wall: 62—600mm.
— Decisions of window frames: galvanized steel or material lining the main plane.
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling.
