The facade system MLK-v-300
Mounting plates of large format porcelain cassette method

— The system allows you to mount large-format sheet material with thickness from 3mm to 3000h1500mm dimensions and more.
— The visible part of the system is minimized, and is 1.2 mm in the contour of the plate.
— It is possible as a purely adhesive and combined (mechanical and adhesive) mounting method.
— Lining Material: large-size slabs of ceramic granite thickness of 3—6 mm.
— Method of attachment facing material: cassettes made of aluminum profiles.
— Maximum size of the lining: 1500h3000mm (horizontal and vertical position).
— Removal of the cladding material from the plane of the wall: 135—588mm.
— Decisions of window frames: galvanized steel, granite.
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling.
