The facade system MTC-v-350
Fixing terracotta plates with aluminum clamps

— Fixing system-clamp "dovetail" into their grooves facing panels provides a reliable and quick fastening of panels with quick dismantling.

— Mounting on horizontal bar allows not to tie vertical rusty cladding to the vertical profiles of the system, to strengthen the lining in Extension and use the narrow slab cladding without substantially increasing the cost of the system.

— Method of attachment facing material: clamps concealed mounting.
— Maximum size of the lining: 600h1800mm
— Location lining: horizontal.
— Removal of the cladding material from the plane of the wall: 62—600mm
— Decisions of window frames: galvanized steel or cladding material
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling
