The facade system MLV-v-20
Attaching cladding panels hidden manner with clasp

— Depending on the type of cladding may mount the Keil anchors, screws Duro-PT, bolts embedded in the ready cladding elements, chemical anchors (stud).
— The organization of the minimum amount of joints (2 mm) without additional processing of plates.
— Lining plates may have any angle in the vertical plane.
— Quick assembly and disassembly of the lining.
— Lining Material: slabs of ceramic granite, natural stone, bumazhnosloistogo plastic (of HPL), concrete panels reinforced with fiberglass (fiberglass), a panel of expanded clay with natural stone surface or a single-layer glass panels of textured GRC, agglomerate, granite slabs, plates of fiber cement.
— Method of attachment facing material: covered fixing agraffas.
— Maximum size of the lining: 1500h1500mm, 1800h1250mm (horizontal and vertical position).
— Removal of the cladding material from the plane of the wall: 62—555mm.
— Decisions of window frames: galvanized steel or material lining the main plane.
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling.
