The facade system MLV-v-20
Attaching cladding panels hidden method for notch

— The system allows you to mount the stones sredneprochnyh breeds, such as the Jura marble.
— The system allows not to tie vertical rusty cladding to the vertical profiles of the system and strengthen the lining "in the Extension."
— Ability to organize removable panels lining.
— Material lining: boards made of ceramic granite, natural stone, textured panels GRC, agglomerate, granite slabs.
— Method of attachment facing material: a hidden fastening clamps, straps.
— Maximum size of the lining: 1500h1500mm, 1800h1250mm (horizontal and vertical position).
— Removal of the cladding material from the plane of the wall: 62—540mm.
— Decisions of window frames: galvanized steel or material lining the main plane.
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling.
