The facade system MLK-v-300
Mounting plates of large format porcelain tiles in a combined way

— The system allows you to mount large-format sheet material with thickness from 3mm to 3000h1500mm dimensions and more.
— Combined (adhesive and mechanical) mounting method.
— Allows you to not tie vertical rusty cladding to the vertical profiles of the system and strengthen the lining "in the Extension."
— The use of composite strips allows quick assembly and disassembly of the panels.
— Lining Material: large-size slabs of ceramic granite thickness of 3—6 mm.
— Method of attachment facing material: composite using horizontal bars with mechanical and adhesive clips to mount to the plates facing.
— Maximum size of the lining: 1500h3000mm (horizontal and vertical position).
— Removal of the cladding material from the plane of the wall: 67—520mm.
— Decisions of window frames: galvanized steel, granite.
bracket mounting options:
— Standard — with fastening to the wall;
— Interstorey — a fixture in the ceiling.
